NSM Electro-Mechanical Manual (USM268)

NSM Electro-Mechanical Manual (USM268)
  • Click to enlarge

€18,32


Product Information
Specification
  • NSM Electro-Mechanical Manual
  • 2nd Hand Used Manual

Contents

  • Location of Components (Century 21)
  • Power Supply & Fuses (Century 21)
  • Electronic Selection System Explained

Century 21 Circuit Description

  • 1 - Credit
  • 2 - Selection Cycle
  • 3 - Write In
  • 4 - Read Out
  • 5 - Trip
  • 6 - Transfer
  • 7 - Play Indicator
  • Power Supply & fuses (Prestige 160C & Consul 160B)
  • Circuit Description (Prestige 160C & Consul 160B)
Product CodeUSM268
ConditionUsed
Weight0.45kg
